Ensure a steady and robust flow of fresh water with our high-pressure fresh water pump. Designed for homes, RVs, and boats, this pump delivers exceptional water pressure, making it perfect for strong, invigorating showers, efficient dishwashing, and consistent faucet flow. Say goodbye to weak water streams, and enjoy the luxury of a high-pressure water supply.
Material :
EPDM(Valves) / Santoprene(Diaphragm)Samples :
AcceptVoltage :
12V/24VCustomized support :
OEM,ODMWarranty :
1 YearProduct Origin :
ChinaAbout this item
Voltage:12V/24V
Open Flow:3.0-5.0GPM / 11.5-18.9LPM
Shut-off Pressure:60-70PSI / 4.2-4.8BAR
Priming Capabilities:6 feet (1.8 m) suction lift
Max Recommended Temperature:140° F (60° C)Max.
Material:EPDM(Valves) / Santoprene(Diaphragm)
Ports:1/2"-14 MNPT
Specification
Type | 5 Chamber positive displacement diaphragm pump, self priming, capable of being run dry |
Control Type | Pressure switch/ bypass |
Max Recommended Temperature | 60° C(140° F) |
Priming Capabilities | 6 feet (1.8 m) suction lift |
Re-start Pressure | Shut-off Pressure 60 PSI :48 PSI ±5 PSI (±0.3 bar) |
Shut-off Pressure 70 PSI :56 PSI ±5 PSI (±0.3 bar) | |
Inlet/Outlet Ports |
1/2"-14 MNPT |
Weight | 5.9 lbs (2.7 kg) |
Leads | 14 AWG, 13" (33 cm) long with 2-Pin connector / Leads |
Duty Cycle | Continuous |
Max.Amp Draw | 18.0 A |
Fuse | 27.0 A |
Model |
Voltage |
Open flow (GPM/LPM) |
Max draw |
Shut-off pressure (PSI / BAR) |
Ports |
Wire connections |
NMDP52-G30-60-12 |
12V |
3.0 / 11.5 |
10A |
60 / 4.2 |
1/2"-14 MNPT |
2-pin / Lead |
NMDP52-G30-60-24 |
24V |
3.0 / 11.5 |
5.5A |
60 / 4.2 |
1/2"-14 MNPT |
2-pin / Lead |
NMDP52-G40-60-12 |
12V |
4.0 / 15.0 |
13A |
60 / 4.2 |
1/2"-14 MNPT |
2-pin / Lead |
NMDP52-G40-60-24 |
24V |
4.0 / 15.0 |
7.0A |
60 / 4.2 |
1/2"-14 MNPT |
2-pin / Lead |
NMDP52-G50-60-12 |
12V |
5.0 / 18.9 |
17A |
60 / 4.2 |
1/2"-14 MNPT |
2-pin / Lead |
NMDP52-G50-60-24 |
24V |
5.0 / 18.9 |
9.0A |
60 / 4.2 |
1/2"-14 MNPT |
2-pin / Lead |
NMDP52-G50-70-12 |
12V |
5.0 / 18.9 |
18A |
70 / 4.8 |
1/2"-14 MNPT |
2-pin / Lead |
NMDP52-G50-70-24 |
24V |
5.0 / 18.9 |
10A |
70 / 4.8 |
1/2"-14 MNPT |
2-pin / Lead |
Dimensions
